1. Hashrate vs. Inlet Coolant Temperature
2. Power Efficiency vs. Inlet Coolant Temperature
(1-1) The hashrate value, and power efficiency on wall are all typical values. The actual hashrate value fluctuates by ±3%, and the actual power efficiency on wall fluctuate by ±5%.
| Specifications
| Product Glance | Value | |||||
| Model | S21 Hyd. | |||||
| Crypto algorithm/coins | SHA256 | BTC/BCH/BSV | |||||
Typical Hashrate, TH/s(2-1) | 319 | |||||
| Power on wall @35°C(2-2), Watt(2-1) | 5104 | |||||
| Power efficiency on wall @35°C(2-2), J/TH(2-1) | 16 | |||||
| Detailed Characteristics | Value | |
| Power Supply | ||
| Phase | 3 | |
| Input voltage, Volt(3-1) | 380~415 | |
| Input frequency range, Hz | 50~60 | |
| Input max current, Amp | 12 | |
| Hardware Configuration | ||
| Network connection mode | RJ45 Ethernet 10/100M | |
| Server Size (Length*Width*Height, w/o package),mm | 339*173*207 | |
| Server Size (Length*Width*Height, with package),mm | 570*316*430 | |
| Net weight, kg | 12.3 | |
| Gross weight, kg | 13.6 | |
| Environment Requirements | ||
Inlet coolant temperature, °C | 20~50 | |
| Coolant flow, L/min | 8.0~10.0 | |
| Coolant pressure, bar | ≤3.5 | |
| Working coolant(3-2) | Antifreeze/Pure water/Deionized water | |
| Coolant pH value | Antifreeze: 7.0~9.0 Pure water: 6.5~7.5 Deionized wate: 8.5~9.5 | |
| Diameter of coolant pipe connector, mm | OD10 | |
| Storage temperature, °C | -20~70 | |
| Operation humidity(non-condensing), RH | 10~90% | |
